SHACKLE KIT & SPRING HANGER
FOR LAND-CRUISER |
| STOCK NO. |
CODE NO. |
PART NO. |
DESCRIPTION OR APPRICABLE
MODELS & YEAR |
REMARKS |
| FTL-801 |
48110K |
04481-60010/12
|
SHACKLE KIT FRONT SPRING |
FJ4#,HJ45,BJ4# 6903-8007 |
| FTL-802 |
48110K |
04481-36020
|
- DO - |
FJ55 6903-8007 |
| FTL-803 |
48110K |
04481-60020/30
|
- DO - |
ALL MDLS FR.FJ40,42,BJ40 RR. 8007- |
| FTL-811 |
48110L |
04482-35020
|
PIN KIT(04482-60010 FRONT SPRING |
FJ,BJ4#,HJ45 6903-7704 FJ55 6903- |
| FTL-812 |
48110L |
04482-60020
|
- DO - FRONT SPRING |
FJ4#,HJ45,BJ4# 7704-8007 |
| FTL-813 |
48110L |
04482-60030
|
- DO - REAR SPRING |
FJ40,BJ40 8001-8007 |
| FTL-814 |
48110L |
04482-60040
|
- DO - FRONT & REAR |
ALL MDLS 8007- EXC. RJ70,LJ70 |
| FTL-821 |
48210K |
04483-35020/30
|
SHACKLE KIT REAR SPRING |
FJ43,45,55,HJ45,BJ43 7903-7901FJ55 |
| FTL-822 |
48210K |
04483-60010
|
- DO - REAR SPRING RH |
FJ40,BJ40 7809-8007 |
| FTL-823 |
48210K |
04483-60020
|
- DO - REAR SPRING LH |
FJ40,BJ40 7809-8007 |
| FTL-824 |
48210K |
04483-60030
|
- DO - REAR SPRING RH |
FJ43,45,HJ45,BJ43 7809-8007 |
| FTL-825 |
48210K |
04483-60040
|
- DO - REAR SPRING LH |
FJ,BJ43 HJ,FJ45 7809-8007 |
| FTL-826 |
48210K |
04483-60011
|
SHACKLE KIT REAR SPRING RH |
FJ40,BJ40,42 8007- |
| FTL-827 |
48210K |
04483-60021
|
- DO - REAR SPRING LH |
FJ40,BJ40,42 8007- |
| FTL-828 |
48210K |
04483-60031
|
- DO - REAR SPRING RH |
FJ43,45,HJ47,BJ43,45,46 8007- |
| FTL-829 |
48210K |
04483-60041
|
- DO - REAR SPRING LH |
FJ43,45,HJ47,BJ43,45,46 8007- |
| FTL-830 |
48210K |
04483-60011
|
- DO - REAR SPRING |
BJ40,42,FJ40 8008- RH, TYPE B |
| FTL-831 |
48210K |
04483-60021
|
- DO - REAR SPRING |
BJ40,42,FJ40 8008- LH, TYPE B |
| FTL-832 |
48210K |
04483-60050
|
- DO - REAR SPRING |
BJ43,46,FJ43 8008- 60# 8008- |
| FTL-833 |
48210K |
04483-60060
|
- DO - REAR SPRING |
BJ70,73,74,FJ70,73, 8411- |
| FTL-834 |
48210K |
04483-60070
|
- DO - REAR SPRING |
BJ75,HJ75,FJ75 8411- |
| FTL-835 |
48210K |
04483-60080
|
- DO - |
FJ,FZJ,HJ,HZJ,PZJ75 9001- |
| FTL-835A |
48210K |
04483-60090
|
- DO - |
FJ,FZJ,HZJ,PZJ70,73 9001- |
| FTL-841 |
48210L |
04484-35011
|
PIN KIT REAR SPRING |
FJ43,45,HJ45,BJ43 6903-8007 |
| FTL-842 |
48210L |
04484-35010/20
|
- DO - FRONT SPRING |
FJ55 6903-8007 |
| FTL-843 |
48210L |
04484-60010
|
- DO - REAR SPRING |
BJ70,73,74,FJ70,73 8411- |
| FTL-844 |
48210L |
04484-60020
|
- DO - |
BJ75,HJ75,FJ75 8411- |
| FTL-844A |
48210L |
04484-60030
|
- DO - |
FJ,FZJ,HZJ,PZJ70,73 9001- |
|
 |
| STOCK NO. |
CODE NO. |
PART NO. |
DESCRIPTION OR APPRICABLE
MODELS & YEAR |
REMARKS |
| FTL-855 |
48110A |
90285-15016
|
BUSH, FR. & REAR SHACKLE |
FJ40,42,BJ40 6903-8001 |
| FTL-856 |
48110A |
90385-15002
|
- DO - |
FJ40,BJ40 8001-8007 |
| FTL-857 |
48110A |
90385-18025
|
- DO - |
FJ43,45,55,HJ43 6903-8007 |
| FTL-858 |
48110A |
90389-18002
|
- DO - |
ALL MDLS 8007- |
| FTL-859 |
48110A |
90385-18009
|
- DO - |
FJ,FZJ,HJ,HZJ,PZJ75 9001- |
| FTL-871 |
48411 |
48411-60032
|
BRACKET RR. R/L FRONT SPRING |
ALL MDLS 8007- EXC. 6#,7# |
| FTL-871A |
48411 |
48411-60050
|
BRACKET FR. RH FRONT SPRING |
BJ7#,HJ75,FJ7# 8411- |
| FTL-871B |
48412 |
48412-60010
|
BRACKET FR. LH FRONT SPRING |
BJ7#,HJ75,FJ7# 8411- |
| FTL-871C |
48414 |
48433-60020
|
BRACKET RR. RH FRONT SPRING |
BJ7#,HJ75,FJ7# 8411- HZJ,PZJ75 |
| FTL-871D |
48415 |
48434-60020
|
BRACKET RR. LH FRONT SPRING |
BJ7#,HJ75,FJ7# 8411- HZJ,PZJ75 |
| FTL-871E |
48414 |
48411-60030/31
|
BRACKET RR. RH/LH FRONT SPRING |
FJ4# HJ45,BJ4#.FJ55 6903-8007 |
| FTL-871F |
48411 |
48411-60060
|
BRACKET FR. RH FRONT SPRING |
FJ75 COLOMBIA SPEC 9105- |
| FTL-871G |
48412 |
48412-60030
|
BRACKET FR. LH FRONT SPRING |
FJ73,75,FZJ73,75 COLOMBIA SPEC |
| FTL-871H |
48414 |
48433-60030
|
BRACKET RR. RH FRONT SPRING |
FZJ75 9208- COLOMBIA SPEC |
| FTL-871J |
48415 |
48434-60030
|
BRACKET RR. LH FRONT SPRING |
FZ75 9208- COLOMBIA SPEC |
| FTL-872 |
48401 |
48414-60021
|
BRACKET FR. RH REAR SPRING |
ALL MDLS 8007- EXC. 60#,7# |
| FTL-873 |
48402 |
48415-60021
|
BRACKET FR. LH REAR SPRING |
ALL MDLS 8007- EXC. 60#,7# |
| FTL-874 |
48411 |
48403-60022
|
BRACKET FR. RH R/L FRONT SPRING |
BJ4#,HJ47,FJ4# 8008-8604 |
| FTL-875 |
48404/5 |
48416-60050
|
BRACKET RR. R/L REAR SPRING |
ALL MDLS 8007- EXC. 60# 7# |
| FTL-876 |
48401 |
48404-60010
|
BRACKET FR. RH REAR SPRING |
BJ70,FJ70 8411- |
| FTL-876A |
48401 |
48404-60020
|
- DO - REAR SPRING |
BJ73,74,FJ73 8411- |
| FTL-876B |
48401 |
48404-60030
|
- DO - REAR SPRING |
BJ75,HJ75,FJ75..HT 8411- |
| FTL-876C |
48401 |
48404-60040
|
BRACKET FR. R/L REAR SPRING |
BJ75,HJ75,FJ75..PIC 8411- |
| FTL-877 |
48402 |
48407-60010
|
BRACKET FR. LH REAR SPRING |
BJ70,FJ70 8411- |
| FTL-877A |
48402 |
48407-60020
|
- DO - REAR SPRING |
BJ73,74,FJ73 8411- |
| FTL-877B |
48402 |
48407-60030
|
- DO - REAR SPRING |
BJ75,HJ75,FJ75..HT 8411- |
| FTL-879 |
48802K |
48802-60010K
|
LINK KIT, STABILIZER |
FJ43,45,HJ45,BJ43 6903-8007 |
| FTL-879A |
48802K |
48802-60030K
|
- DO - |
FJ80,HDJ80,HZJ80 9001- |
|
