FRONT & REAR DIFFERENCIAL
FOR LAND-CRUISER

STOCK NO. CODE NO. PART NO. DESCRIPTION OR APPRICABLE
MODELS & YEAR
REMARKS
FTL-551 41101 41101-60021 CARRIER SUB ASSY (41101-60H00) ALL MDLS 6903-8411 EXC. 7#
FTL-551A 41101 41101-60040 - DO - BJ7#,HJ47,75,FJ4#,7# 8411-8604
FTL-551B 41101 41101-60080/81 - DO - BJ7#,HJ75,FJ7#..RHD 8606-
FTL-551C 41101 41101-35070/71 - DO - RJ70 8510-
FTL-551D 41101 41101-60060/61 - DO - RJ70,LJ70..GEN BJ70,73..LHD 8708-
FTL-555 41101 41110-60906 CARRIER ASSY R=37:10 FOR DIFF FLANGE 41204-35010/11
FTL-556 41101 41110-60025/26 - DO - R=37:10 FOR DIFF FLANGE 41204-35020/21
FTL-557 41101 41110-60015/16 - DO - R=37:9 FOR DIFF FLANGE 41204-60010
FTL-558 41101 41110-60907 - DO - R=37:9 FOR DIFF FLANGE 41204-35010/11
FTL-559 41101 41110-60110 - DO - R=37:9(K082) BJ7#,HJ75,FJ7#..ARL,GEN,ME 8411
FTL-560 41101 41110-60120 - DO - R=37:9(K055) FJ7# 8411-8608 FJ75..RHD 8608-
FTL-561 41101 41110-60130 - DO - R=37:9(K085) BJ7#,HJ75,FJ7#..APR,GEN,ME 8411
FTL-562 41101 41110-60230 - DO - R=37:9(K084) BJ7#,HJ75,FJ7# 8608-
FTL-571 41201 41201-69036 FINAL GEAR SET N=37:10 FJ4#,55,6908-7608 (*1)
FTL-572 41201 41201-69046 - DO - N=37:9 FJ4#,55,HJ45,BJ4# 7308-7501 (*2)
FTL-573 41201 41201-69105 - DO - N=37:9 FJ4#,55,BJ4# GEN ARL 7801-
FJ60,HJ60,BJ60 8007-
FTL-573A 41201 41201-69165/66 - DO - N=37:9 BJ7#,HJ75,FJ7# 8411-
FTL-574 41201 41201-69095 - DO - N=37:10 FJ4#,55,GEN EUR 7801-8007
HJ60,RJ60 GEN EUR 8007-
FTL-574A 41201 41201-69155/56 - DO - N=37:10 FJ7#..MTM 8411- HJ75..SA 8510-
FTL-575 41201 41201-29645 - DO - N=41:9 RJ70 8510-
FTL-576 41201 41201-39705 - DO - N=39:8 RJ70,LJ70..GEN 8510-
FTL-577 41201 41201-69225 - DO - N=41:11 FJ70,73 9001-9208 FJ80..MTM 9001-
FTL-577A 41201 41201-69235 - DO - N=41:10 FJ80,HDJ80,HZJ80 9001-
FTL-577B 41201 41201-69245 - DO - N=41:11 FJ80..MTM REAR 9001-
FTL-577C 41201 41201-69255 - DO - N=41:10 FJ80,HDJ80,HZJ80 REAR 9001-
FTL-577D 41201 41201-69265 - DO - N=37:9 FJ70,73,75,FZJ7#,HZJ7#,PZJ7# 9001-
FTL-577E 41201 41201-69325 - DO - N=41:9 RJ7# 9001-
FTL-577F 41201 41201-69335 - DO - N=41:9 PZJ7# 9001-
FTL-577G 41201 41201-69345 - DO - N=39:8 LJ7#,RJ7# 9001-
FTL-577H 41201 41201-69405 - DO - N=41:9 PZJ7# 9001-
FTL-577J 41201 41201-69435 - DO - N=37:9 FZJ,HZJ,PZJ7# 9108-


STOCK NO. CODE NO. PART NO. DESCRIPTION OR APPRICABLE
MODELS & YEAR
REMARKS
FTL-581 41222A 41226-35010 BOLT, RING GEAR ALL MDLS 7205- EXC. RJ70,LJ70
FTL-581A 41222A 90101-11353 - DO - RJ70,LJ70 8411- HILUX RN,YN,LN
FTL-582 41222A 90179-12134 NUT, RING GEAR ALL MDLS 7205- EXC. RJ70,LJ70
FTL-583 41201C 90311-38134 OIL SEAL, DEFF CARRIER ALL MDLS 7308- EXC. RJ70,LH70
FTL-585 41204A 90201-20329 WASHER, DIFF FLANGE ALL MDLS 6903- 7801-
FTL-586 41204A 90201-20005 - DO - ALL MDLS 7801- EXC. 7# 8411-
FTL-586A 41204A 90201-22007 - DO - BJ7#,HJ75,FJ7# 8411-
FTL-587 41204B 90179-20061 NUT, DIFF FLANGE ALL MDLS 6908-7801
FTL-588 41204B 90179-20001 - DO - ALL MDLS 7801- EXC. 7# 8411-
FTL-589 41204B 90179-22011 - DO - BJ7#,HJ75,FJ7# 8411-
FTL-590 41331 41331-25010 GEAR, DIFF. SIDE FJ80,HDJ80,HZJ80,9001-
FTL-591 41331 41331-35020 - DO - ALL MDLS 6903- EXC.LSD DIFF LOCK
FTL-591A 41331 41331-60010 - DO - BJ,FJ7#,HJ75,W/LSD 8411- 80# 9001-
FTL-591B 41331 41331-60020 - DO - BJ7#,HJ75,FJ7# RHD DIFF LOCK 8606
FTL-591C 41331 41331-35010/11 - DO - RJ70,LJ70 8411-8510
FTL-591D 41331 41331-35030 - DO - RJ70,LJ70 W/LSD 8411-
FTL-591E 41331 41331-35040 - DO - RJ70,LJ70 8510-
FTL-592 41341 41341-55010/12 GEAR, DIFF. PINION ALL MODELS 6903- EXC.LSD,DIFF LOCK
FTL-592A 41341 41341-60010 - DO - BJ7#,HJ75,FJ7# W/LSD 8411-
FTL-592B 41341 41341-35010 - DO - RJ70,LJ70 W/LSD 8411-RN,YN,LN 8408
FTL-592C 41341 41341-35020 - DO - (41341-30052) (41341-39020) RJ70,LJ70 8411-8510 RN,YN,LN,8308-
FTL-592D 41341 41341-25010 - DO - FJ80,HDJ80,HZJ80,9001-
FTL-593 41342 41342-55010 SHAFT, DIFF. PINION ALL MDLS 6903- EXC. LSD. DIFF LOCK
FTL-593A 41342 41342-60010 - DO - BHFJ7# DIFF LOCK L=136 8608-
FTL-593B 41342 41342-60020 - DO - NO.2 BHFJ7# DIFF LOCK L=60.5 8606-
FTL-593C 41342 41342-39610 - DO - RJ70,LJ70 8411-8510 RN,YN,LN 8308-
FTL-594 41344 41344-35010 SPACER, DIFF PINION ALL MDLS 6903- EXC. LSD,RJ70,LJ70


STOCK NO. CODE NO. PART NO. DESCRIPTION OR APPRICABLE
MODELS & YEAR
REMARKS
FTL-595 41302 41311-36010 CASE SUB ASSY ALL MDLS 6903- EXC. MDLS BELOW
FTL-595A 41302 41311-40020 - DO - RJ,LJ70 8411-8510 RN,LN,YN5,6,10#
FTL-595B 41302 41301-60010/11 - DO - BJ7#,HJ75,FJ7# LSD 8411-
FTL-595C 41302 41301-60020/21 - DO - BJ7#,HJ75,FJ7# W/DIFF LOCK 8608-
FTL-595D 41302 41301-35010 - DO - (41311-35010) BJ70,73..LHD 8708-
FTL-595E 41302 41302-35010 - DO - RJ70,LJ70 W/LSD 8411- YN,LN5,6,10#
FTL-595F 41302 41302-35020 - DO - RJ70,LJ70 8510- VZN130 9008-
FTL-595G 41302 41301-60040 - DO - FJ80,HDJ80,HZJ80 9001-
FTL-595H 41302 41301-60060 - DO - L,R,J7#,F,HZ,H,FZ,PZ,J7# 8# 9001-
FTL-595J 41302 41311-60070 - DO - FJ,HZJ,HJ,HZJ,PZJ7# 8# 9001-
FTL-596 41351 41351-35010/11 WASHER, DIFF. PINION ALL MDLS 6903- EXC. MDLS BELOW
FTL-596A 41351 41351-60010 - DO - BJ7#,HJ75,FJ7# W/LSD 8411-
FTL-596B 41351 41351-30052 - DO - (0.5m/m) RJ70,LJ70 8411-8510 RN,YN,LN
FTL-596C 41351 41351-30060 - DO - RJ70 LSD 8411-8510, R,LJ70 8510
FTL-596D 41351 41351-30051 - DO - (0.9m/m) YN,LN5#,6# 8308-8408
FTL-597 41361 41361-35010 WASHER, DIFF. SIDE (41361-60010) ALL MDLS 6903- EXC.LSD MDLS BELOW
FTL-597A 41361 41361-40020/21 - DO - RJ70,LJ70 8411-8510 RN,LN,YN5#,6#
FTL-597B 41361 41361-24010 - DO - RJ70,LJ70 8510-
FTL-598 41231 41231-24010 SPACER F,HD,HZ,J80# F,FZ,HZ,PZ,J7# 9001-
FTL-598A 41231 41231-40010 - DO - RJ70,LJ70 8411-8508
FTL-598B 41231 41231-40011 - DO - R,LJ70 8505 L,R,YN5,6,8,10,12,13#
FTL-598C 41231 41231-60020 - DO - BJ,HJ,FJ7# 8411-
FTL-598D 41231 41231-60030 - DO - FJ,FZJ,HJ,HZJ,PZJ7# 9001-
